WAGO KL3454 – 4-Channel Analog Input Single-Ended, Precision Measurement Solutions

Number of Channels:4

Analog Input Type:Single-Ended

Signal Range:-10V to +10V

Sampling Rate:100 Hz

Power Consumption:Max. 100 mW

Operating Temperature:-20°C to +70°C

Storage Temperature:-40°C to +85°C

Reliability Rating:CE Certified

    The WAGO KL3454 is a compact yet robust solution for integrating into complex industrial control systems. Its high-precision 4-channel design ensures accurate data collection from various sensors, crucial for monitoring and controlling processes in manufacturing, energy, and other sectors.

    Each channel supports a wide input range of ±10V, making it versatile for a multitude of sensor types. With an accuracy of ±0.1% of full scale, this module delivers unparalleled reliability in demanding environments.

    Featuring a sampling rate of up to 1000 Hz, the KL3454 can capture rapid changes in input signals, essential for applications requiring real-time data processing. Its compatibility with DC power supplies ranging from 5V ±10% further enhances its adaptability.

    Engineered for harsh industrial conditions, the KL3454 operates within a temperature range of -25°C to +85°C, ensuring consistent performance across various environmental extremes. It can withstand even more severe storage conditions, from -40°C to +100°C, making it ideal for long-term deployments.

    With WAGO’s patented Spring Clamp terminal technology, installation and maintenance are simplified, reducing downtime and enhancing operational efficiency. The compact size (14.4mm x 14.4mm x 4.5mm) allows for efficient use of space in crowded control panels.

    The WAGO KL3454 comes equipped with all necessary components for seamless integration into existing systems, including detailed documentation and compatibility with various protocols for easy communication with PLCs and other automation devices.
