Bandwidth:500 MHz
Sample Rate:2.5 GS/s
Channels:4
Record Length per Channel:20 Mpts
Waveform Update Rate:250,000 wfm/s
Horizontal Resolution:8 bits
Vertical Resolution:8 bits
Display:10.4″ XGA color display
Connectivity:USB 2.0, Gigabit Ethernet, HDMI
Form Factor:Portable
The Tektronix DPO5054B Digital Phosphor Oscilloscope is designed to meet the needs of modern electronics engineers and technicians. Featuring a 500 MHz bandwidth, this oscilloscope ensures precise measurements across a wide range of frequencies. Its 4-channel capability allows for simultaneous observation of multiple signals, which is invaluable in diagnosing complex systems. The oscilloscope boasts a high sample rate of 5 GS/s, enabling it to capture transient events in real-time. With a record length of 20 million points per channel, users can analyze long-term trends without sacrificing resolution. Enhanced by a waveform capture rate of 200,000 wfm/s, it quickly identifies even the most fleeting signals. This oscilloscope comes equipped with USB 2.0, Ethernet, and HDMI out interfaces, ensuring seamless integration into various work environments. Its user-friendly interface includes programmable function keys and multi-language support, making it accessible to a global audience.
