Tektronix 5A18N Arbitrary Function Generator

In stock

The Tektronix 5A18N Function Generator offers high precision arbitrary waveform generation, making it ideal for testing and debugging electronic circuits. It supports various waveforms and frequencies, providing flexibility for a wide range of applications.

Frequency Range:Up to 20 MHz

Output Amplitude:2 Vpp to 10 Vpp

Waveform Types:Sine, Square, Triangle, Pulse

Frequency Resolution:0.1 Hz

Amplitude Resolution:0.1 Vpp

Signal Purity:≤ -80 dBc @ 1 kHz

The Tektronix 5A18N Signal Generator is an essential tool for engineers working in industrial control systems. Its precision and versatility make it ideal for generating a wide range of waveforms with exceptional accuracy and stability. The module supports various waveform types including sine, square, triangle, pulse, and ramp, allowing for flexible testing scenarios. With a frequency range from 0 Hz to 50 MHz and an amplitude range from 0.1 Vpp to 10 Vpp, this generator can handle a broad spectrum of industrial control requirements. The output impedance of 50 Ω ensures reliable connections and minimal signal loss. The harmonic distortion of ≤ -60 dBc guarantees clean and accurate signals. Designed with user convenience in mind, the 5A18N includes phase shift functionality ranging from 0° to 360°, enabling precise control over waveform characteristics. Easy to integrate into existing systems, this module provides seamless operation with its intuitive interface and robust performance.

TEKTRONIX 5A18N
