Winding Configuration:2 windings per phase
Resistant Temperature Device (RTD):Type 3 wire; 100 Ω Nickel, 120 Ω Nickel, 100 Ω Platinum
Analog Output Maximum Load:10 kΩ at 0 to 1 mA, 600 Ω at 4 to 20 mA
Maximum Continuous Voltage Output:273 V
Display Type:40-character Enhanced LCD
Dimensions:9”H x 7”W x 7 ⅛”D
Control Power Range:90 to 300 V DC; 70 to 265 V AC at 48 to 62 Hz
The GE SR745-W2-P1-G1-HI-E-H is designed for managing and protecting transformers, autotransformers, and reactors. It features an advanced 40-character display and an expanded keypad, making it easier to manually enter setpoints and monitor status updates in real-time.
This enhanced control system offers a user-friendly interface with a height of 9 inches, a width of 7 inches, and a depth of 7 ⅛ inches, ensuring efficient space utilization within control panels.
The transformer protection system can be easily mounted on a standard 19-inch panel, providing reliable protection and monitoring capabilities for critical electrical components.
With multiple LED indicators on the front of the case, users can quickly identify various statuses and errors in real-time, enhancing operational efficiency and safety.
Designed for robust performance, this system operates within a wide range of voltages and frequencies, making it suitable for diverse industrial applications where precision and reliability are paramount.
