GE 369-HI-R-M-0-0-0: Motor Management Relay with Enhanced Metering and Waveform Capture

In stock

The GE 369-HI-R-M-0-0-0 is a high-performance motor management relay designed to enhance motor protection and control systems. With waveform capture, event reports, and data logging, it provides critical insights into system performance and helps reduce maintenance costs.

Control Power nominal:20 VA

Control Power maximum:65 VA

Control Power Input Range:110 to 250 VDC, 100 to 240 VAC at 50/60 Hz

Dimensions:approx. 12 in H x 5 in W x 8 in L

Ground Current Input Frequency:20 to 100 Hz

Insulation Class:I

Phase Current Input Conversion:True RMS, 1.04 ms/sample

Weight:4.5 kg

Optional Metering Feature:Included

RTD Inputs:12

The GE 369-HI-R-M-0-0-0 is a cutting-edge motor management relay equipped with an array of advanced features. This model boasts waveform capture, event reports, and data logging functionalities, providing essential insights into system performance and early warnings of potential issues. With built-in metering capabilities, it efficiently monitors and manages motor systems, making maintenance easier and more cost-effective. Designed with robust specifications including a control power range of 110 to 250 VDC and 100 to 240 VAC, the 369-HI-R-M-0-0-0 ensures reliable operation across various industrial environments. Its true RMS phase current input conversion ensures accurate measurements, while its lightweight design (approximately 4.5 kg) makes installation straightforward. Whether you are managing large industrial motors or seeking a comprehensive solution for motor protection, the GE 369-HI-R-M-0-0-0 is an indispensable tool for industrial control systems.

GE 369-HI-R-M-0-0-0
