Control Power Input Range:110 to 250 VDC, 100 to 240 VAC at 50/60 Hz
Ground Current Input Frequency:20 to 100 Hz
Operating Range:-40°F to +140°F
Phase Current Input Conversion:True RMS, 1.04 ms/sample
Storage Range:-40°F to +176°F
Waveform Capture Length:3 buffers containing 16 cycles of all current and voltage channels
The GE 369-HI-0-0-0-0 Motor Management Relay is a highly reliable solution for protecting and monitoring medium to large motors. This relay is designed to handle a wide range of motor management tasks with precision and efficiency. It includes essential protection features such as undervoltage auto-restart, reverse power protection, and various demand monitoring options like kVA, kvar, and kW demands. Additionally, it offers real-time monitoring of current demand, backspin detection, self-test/service functions, trip counters, and loss of RRTD communications.
The relay operates within a broad control power range of 110 to 250 VDC and 100 to 240 VAC at 50/60 Hz, making it suitable for diverse industrial applications. With a differential switch time delay of less than 200 ms, it ensures rapid response times for critical protection scenarios. Its compact dimensions of approximately 29.6cm H x 10.7cm W x 20.5cm L make it easy to integrate into existing systems.
Designed with safety and reliability in mind, the relay features Class I insulation, ensuring safe operation under various conditions. It supports phase current inputs of 1 A and 5 A secondary, along with RTD inputs for precise temperature monitoring. Weighing approximately 10 lbs, this relay is robust yet lightweight, facilitating installation and maintenance.
Whether you are managing motors in manufacturing plants, energy facilities, or other industrial environments, the GE 369-HI-0-0-0-0 Motor Management Relay offers unmatched protection and monitoring capabilities. Invest in quality and reliability with this advanced motor management solution.
