Allen Bradley AB 1747-L524 PROCESSOR MODULE – Modular Automation Control

Processor Type:Modular

Controller Model Number:1747-L524

Manufacturer:Allen-Bradley

Memory:16 KB

Backup:Flash

Interface:RS-232 Ports

Communication Protocol:EtherNet

Mounting Type:Chassis

Output:Backplane: 1 MA at 5 VDC

Response Time:Typical Scan: 0.9 MS/Kword, Bit Execution: 0.37 MIC-SEC, I/O Scan: 0.255 MS

Programming Device:RSLogix™ 5000 Software

Enclosure Type:Open Type

Display:Status LEDs

Length:145 MM

Width:35 MM

Height:142 MM

Temperature Rating:0 – 60 DEG C

Environmental Conditions:5 – 95%

    The AllenBradley AB 1747-L524 Processor Module is engineered to meet the stringent demands of industrial environments, offering a balance of reliability, efficiency, and versatility. With its modular design, this processor module can be easily integrated into existing systems or as part of new automation setups, enhancing operational performance.

    Featuring an impressive memory capacity of 16 KB, the module ensures efficient handling of complex programming tasks, while its robust backup system using flash technology guarantees data integrity even under unexpected power disruptions. The inclusion of multiple RS-232 ports facilitates versatile communication with other devices, and the built-in EtherNet interface supports seamless connectivity in modern industrial networks.

    Designed for compatibility with the latest software tools such as RSLogix™ 5000, users can leverage advanced programming capabilities to tailor their control strategies precisely. The open type enclosure ensures adequate ventilation, crucial for maintaining optimal operating temperatures within industrial settings.

    The inclusion of status LEDs provides real-time feedback on the module’s operational status, enabling quick troubleshooting and maintenance actions without the need for specialized equipment. The compact dimensions of the AB 1747-L524 Processor Module ensure it fits into space-constrained industrial setups, making it suitable for a wide range of applications.

    With its comprehensive feature set and compatibility with various communication protocols, this processor module is an excellent choice for manufacturers looking to upgrade or expand their automation capabilities. Whether in food processing, automotive assembly lines, or any other industrial sector, the AllenBradley AB 1747-L524 Processor Module delivers the precision and reliability required for demanding operations.
