Number of Channels:8
Type of Input:Digital
Common Mode Voltage Range:-20V to +20V
Absolute Input Voltage:+/- 7.5VDC or +/- 7.5VAC RMS (Max.)
Input Range:-20mA to +20mA
Current Rating:Backplane: 125mA @ 5VDC, 75mA @ 24VDC
Isolation:500VAC isolation for 1 sec
Power Rating:Backplane: 2.425W
Enclosure Type:Open Type
The AB 1746-NO8I Input Module SLC 500 Analog is a robust solution for industrial automation, featuring a compact design that ensures seamless integration into various control systems. This module supports up to 8 channels of analog input, providing flexibility for a wide range of industrial applications.
With an operating voltage of 24VDC, it ensures reliable operation across different industrial environments. The module’s exceptional accuracy at 20°C, ±0.05%, makes it suitable for precision-sensitive applications, ensuring that data collected is highly accurate.
Designed for operation within a temperature range of -40°C to +70°C, this module is built to withstand extreme environmental conditions commonly found in industrial settings. Its relative humidity tolerance of 5% to 95% non-condensing ensures continuous performance under varying climatic conditions.
Equipped with communication rates of 57.6 kbit/s, 115 kbit/s, and 230 kbit/s, the AB 1746-NO8I ensures efficient data transfer between devices, enhancing the responsiveness and reliability of your automation system.
This input module comes with a weight of 0.6 lbs, making it lightweight and easy to install in tight spaces. Its compact dimensions of 4.5 x 4.5 x 1.25 inches further facilitate its integration into existing control panels and systems, minimizing space requirements.
