Operating Voltage:24VDC
Current Rating:1 Amp
Number of Inputs:16 digital inputs
Number of Outputs:16 digital outputs
Communication Protocol:DeviceNet
Operating Temperature:-20°C to +70°C
Power Consumption:1W
Dimensions (WxHxD):50mm x 80mm x 30mm
Weight:35g
The ABB DSQC563 boasts a robust design, engineered to withstand harsh industrial environments, ensuring long-lasting reliability. Its compact form factor facilitates easy integration into existing control systems without compromising on functionality.
Equipped with 8 digital input channels, this module provides versatile connectivity options, allowing for the monitoring of various mechanical and electronic sensors. Each input channel is designed to handle a wide range of signals, enhancing its applicability across different industries.
Featuring 4 relay output channels, the DSQC563 enables precise control over actuators and devices, facilitating the automation of processes with high precision and efficiency. The relay outputs are capable of handling a variety of loads, making it suitable for a broad spectrum of applications.
Withstanding extreme temperature conditions from -25°C to +60°C during operation and -40°C to +85°C during storage, the DSQC563 ensures operational reliability in diverse environmental settings. This makes it an ideal choice for manufacturers operating in varied geographical locations.
In terms of power consumption, the DSQC563 is optimized for energy efficiency, drawing a maximum of 50mA per channel, which helps in reducing overall system costs and environmental impact.
