A-B 1444-REL-RPC-SCW-01 Screw Clamp Removable Connector Set – Industrial Control Automation Module

Type:USB connector, screw-clamp terminal connections (I.O’s)

Communication Protocol:RS-422

Net Width (mm):175 mm

Mounting Mode:DIN rail

Digital Inputs:36 x digital inputs (24Vdc; Sink/Source)

Digital Outputs:24 x digital outputs (5-30Vdc; Sink; 500mA; 0.2ms response)

Dimensions:W175mm x H90mm x D86mm

Operating Temperature Range:0…+55 °C

Storage Temperature Range:-25…+75 °C

Programming Languages Supported:Ladder diagram (LD) / Relay symbol language, Structured Ladder / Function Block Diagram (FBD), Structured Text (ST), Sequential Function Chart (SFC)

Processing Time:0.21μs / instruction

    Designed for industrial automation, the A-B 1444-REL-RPC-SCW-01 Screw Clamp Removable Connector Set ensures robust connectivity in high-performance systems. Its screw-clamp terminals provide a secure connection method, reducing the risk of loose wiring that can lead to system failures. The connector set supports multiple communication protocols including RS-422, making it versatile for various industrial applications.

    With 36 digital input channels and 24 digital output channels, this connector set can handle complex control scenarios efficiently. Each output channel supports up to 500mA current and has a fast response time of 0.2ms, ideal for real-time control systems. The compact size of 175mm x 90mm x 86mm allows for easy installation on standard DIN rails without taking up excessive space.

    The wide operating temperature range from 0°C to +55°C and storage temperature range from -25°C to +75°C make it suitable for use in a variety of environmental conditions, including harsh outdoor settings. Furthermore, the connector set is compatible with multiple programming languages such as Ladder diagram, Structured Ladder, Structured Text, and Sequential Function Chart, allowing for flexible system design and programming.

    By using the A-B 1444-REL-RPC-SCW-01 Screw Clamp Removable Connector Set, industrial control systems can achieve higher reliability, faster response times, and easier maintenance. Whether you are building new systems or upgrading existing ones, this connector set is an essential component for achieving superior performance and efficiency.
